Movamax 100/175/200 Watt 12 Volt Monocrystalline Solar Panel Module PV Charger (Compact Design)

100W

High in power, compact in size, this Movamax 100 Watt 12 Volt Monocrystalline Solar Panel is the perfect option for any off-grid application. Ideal for RVs, motorhomes, cabins, marine areas, home backup power, and more. The panels feature lightweight aluminum frames and shatter-resistant glass, making them perfect for outdoor applications. It comes with pre-drilled mounting holes, solar connector leads, and a junction box. Allowing you to install, connect it to a controller, or expand with panels without breaking a sweat. The panels are made of premium Grade A+ monocrystalline solar cells that are more efficient than conventional polycrystalline solar cells. Since 2019, Movamax has gained rich experience designing and manufacturing the most efficient and robust solar panels and complete off-grid solar systems. Movamax's focus on testing, quality control, and traceability ensures our solar power system offers industry-leading reliability. Invest in yourself by going Movamax. Movamax solar panels will be your most economical long-term investment yet.

【Reliable Power Output】 Movamax's 100W monocrystalline solar panel can provide an average of 400-500 Watt-hours (Wh) or 33-41Amp-hours (Ah) of electricity per day (depending on sun availability).

【Efficient Performance】 Bypass diodes protect the solar cells from overheating and allow the solar panel to continue working during accidental shading by bypassing the underperforming cells.

【Industry-Leading Technology】 Each Movamax 100W 12V Monocrystalline Panel is made from high purity silicon cells coated with advanced encapsulation material with multi-layered sheet laminations to enhance cell performance and provide long-lasting durability.

【Built to Last】 Corrosion-resistant aluminum frame provides extended outdoor use that ensures the panel can last for decades. The IP65 rated junction box is versatile due to its ability to withstand dirt, dust, debris, and low-pressure water jets.

【Fast and Easy Installation】 Pre-drilled holes on the back of the panel allow for fast mounting and securing, ideal for off-grid applications including RVs, rooftops, cabins, yachts, and more. They are directly compatible with Movamax ground mounts, Z Brackets, Corner Brackets, Pole Mounts, and Tilt Mounts.

Specification

Max Power at STC: 100 W

Open Circuit Voltage: 24.3 V

Short Circuit Current: 5.21 A

Optimum Operating Voltage: 20.4 V

Optimum Operating Current: 4.91 A

Cell Efficiency: 22.00%

Operating Temperature: -40°F to 176°F

Panel Leads (Pair): 14 AWG (1.96 ft)

Module Efficiency: 17.80%

Maximum Series Fuse Rating: 15A

Cell Type: Monocrystalline (6.5 x 3.3 in)

Number of Cells: 36 (3 x 12)

Front Glass: Tempered Glass 0.13 in (3.2 mm)

Frame: Anodized Aluminium Alloy

Connectors: MC4001 Solar Connectors

Fire Rating: Class C

Operating Temperature: -40°F to 176°F

Nominal Operating Cell Temperature (NOCT): 47±2ºC

Temperature Coefficient of Pmax: -0.37%/ºC

Temperature Coefficient of Voc: -0.28%/ºC

Temperature Coefficient of Isc: 0.048%/ºC

Solar Connectors

Rated Current: 30 A

Maximum Voltage: 1000VDC

Maximum AWG Size Range: 10 AWG

Temperature Range: -40ºF to 194ºF

IP Rating: IP 67

Junction Box

IP Rating: IP 65

Diode Type: HY 10SQ050

Number of Diodes: 2 Diode(s)

Output cables (pair): 14 AWG (1.96 ft)

Material and workmanship warranty: 5 years

Certifications: CE, ISO

175W

The Movamax 175 Watt 12 Volt Monocrystalline Solar Panel is a key component to any solar power (PV) system. Each solar panel includes solar connectors that extend from the junction box affixed to the back of each panel. The solar connectors are compatible with the Movamax solar connector Adaptor Kit - allowing for a quick and simple connection. Whether you take it camping in the mountains or for a trip to the beach, this off-grid panel can be a great start or addition to any Movamax off-grid system! Each Movamax 175W Monocrystalline Solar Panel is capable of withstanding heavy snow and strong wind loads. Each panel is quality tested to ensure safety and longevity.

Key Features

Reliable

Multi-layered sheet laminations enhance cell performance and ensure a long service life

EL tested solar modules; no hot-spot heating guaranteed

Bypass diodes minimize power drops caused by shade and ensure excellent performance in low-light environments

TPT back sheet dissipates heat to ensure smooth performance over a long period of time

Pre-installed corner protector protects you from accidental cuts from the sharp corners and protects solar panel frame from impacts

Durable

Guaranteed positive output tolerance (0-3%); withstands high winds (2400Pa) and snow loads (5400Pa)

A corrosion-resistant aluminum frame allows for extended outdoor use with a typical lifespan of decades

Anti-reflective, high transparency, low iron-tempered glass with enhanced stiffness and impact resistance

IP65 rated junction box provides complete protection against environmental particles and low-pressure water jets

Versatile

Can be used for many different applications

Ground mount compatible

Compatible with on-grid and off-grid inverters

Installation Ready

Pre-drilled holes on the back of the panel allow for fast mounting and securing

Pre-drilled holes are included for grounding

Compatible with a variety of Movamax mounting systems such as Z-Brackets, Pole Mounts and Tilt Mounts

Specification

Max Power at STC: 175W

Open Circuit Voltage: 21.6V

Short Circuit Current: 10.35A

Optimum Operating Voltage: 17.95V Optimum Operating Current: 9.75A Operating Temperature: -40°F to 176°F (-40°C to 80°C)

Maximum System Voltage: 600VDC UL Maximum Series Fuse Rating: 15A Cables: 12 AWG 2.3ft

Dimensions: 52.2x26.3x1.38 in (1326*668*35mm)

Weight: 19.8 lbs (9Kg)

Solar Cells: 32 Monocrystalline Cells Junction Box: IP65

Connectors: Male and Female Connectors

Module Efficiency: 19.80%

200W

The Movamax 200 Watt 12 Volt Monocrystalline Solar Panel is one of the main components for any solar power (PV) system. The panel includes MC4 leads that extend from the junction box affixed to the back. The MC4 leads are compatible with the Movamax MC4 Adaptor Kit—allowing for a quick and simple connection. Each Movamax 200W Monocrystalline Solar Panel is quality tested to ensure safety and longevity. Built durable for outdoor use, these panels are capable of withstanding heavy snow and strong wind loads. Whether you plan to use the solar panel for seaside travels to the beach or your cabin in the mountains, this panel can be a great start or addition to any Movamax off-grid system!

Key Features

Reliable

Advanced encapsulation material with multi-layered sheet laminations enhance cell performance and provide a long service life

EL-tested solar modules; no hot-spot heating guaranteed

Bypass diodes minimize power drop caused by shade

TPT back sheet ensures smooth performance over a long period of time

Durable

Guaranteed positive output tolerance (0-3%); withstands high winds (2400Pa) and snow loads (5400Pa)

Corrosion-resistant aluminum frame allows extended outdoor use; the panels can last for decades

Anti-reflective, high transparency, low iron-tempered glass with enhanced stiffness and impact resistance

IP65 rated junction box provides complete protection against environmental particles and low-pressure water jets

Versatile

Can be used for many different applications

Ground mount compatible

Compatible with on-grid and off-grid inverters

Installation Ready

Pre-drilled holes on the back of the panel allow for fast mounting and securing

Pre-drilled holes included for grounding

Compatible with different Movamax mounting systems such as Z-Brackets, Pole Mounts, and Tilt Mounts

Specifications

Max Power at STC: 200W

Open Circuit Voltage: 24.1V

Short Circuit Current 10.9A

Operating Voltage 21.0V

Operating Current 9.52A

Operating Temperature: -40℃ to 80℃ (-40°F to 176°F)

Maximum System Voltage 1000 VDC UL

Maximum Series Fuse Rating 15A

Maximum Series Fuse Rating 15A

Product Dimensions (mm)/(inch) 1650 x 670 x 35 mm (64.96*26.38*1.38 in)

Product Weight (g)/(oz) 11.5 kg (25.4 lb)
